Edition du : 16/04/2024 14:21



DEGREASING SOLVENT FOR A3

VACUUM MACHINES

WITH RECYCLING







NEUTRALENE® 1089 AM

MODIFIED ALCOHOLS

FLASH POINT ISO 2719

66°C

DISTILLATION RANGE ISO 3405

at atmopheric pressure

182°C - 190°C





A3 solvent degreasing machines have been developed to meet the toxicity problems encountered with chlorinated solvents classified as CMR (Carcinogenic, Mutagenic, Reprotoxic).

In order to avoid any health risk for the operators, they are closed. Under vacuum, they enable the final distillation point to be lowered by about 30%, and finally they enable the recycling of solvents, for degreasing with clean products.



A3 solvents are classified into 3 families.

Hydrocarbons are all classified H 304 "May be fatal if swallowed and enters the respiratory tract". Most of the time, they have the glycol ethers (alcohols) as additives to reinforce their solvent power, which are themselves classified as H315 class 2 skin irritants, and H319 causes severe eye irritation.

Modified alcohols, which are not H 304, but remain H 315 and H 319.

Fluorinated products, the future of which is uncertain according to the F. Gas Directive. (EU Regulation 517/2014) on the environmental impact of fluorinated gases with global warming potential. This regulation is expected to be tightened further with the "Ecocide" draft legislation



In order to resolve the health risks linked to the first 2 families, users have packaging designed so that there is no possible risk of contact available to them (often through rental).



NEUTRALENE 1089 AM is part of the Modified Alcohol series, and was designed to be:

The first degreasing solvent without danger pictograms

- Elimination of security overpacks

- Reinforced solvent power, allowing use both hot and cold, extending its use in conventional solvent degreasing fountains, immersion tanks, with rotary or linear movement of baskets, ultrasonic tanks with piezoelectric or magnetostrictive generators,

- High settling power of mineral oils by density differential.

- Outdoor storage allowed, without retention, the retention obligation being subject to the Labour Code article R 4412 and the ICPE code.

Jacques Tardif     iBiotec    Tec industries         Tec investissements

Jacques P. TARDIF

Technical Director



AREAS OF USE

Cold or hot degreasing of all organic pollution, greases including solid lubricants, mineral or synthetic oils, machining fluids, shearing and stamping lubricants. RMO or MCO degreasing of all mechanical components.



TYPICAL PHYSICAL AND CHEMICAL PROPERTIES

PROPERTIES

  STANDARDS

VALUES

UNITS

Appearance

  Visual

Clear

-

Colour

  Visual

 Colourless

-

Odour

  Olfactory

Light characteristic

-

Density at 25°C

  NF EN ISO 12185

0.901

kg/m3

Refractive index

  ISO 5661

 1.4160

-

Freezing point

  ISO 3016

-60

°C

Kinematic viscosity at 25°C

  NF EN 3104

2.3

mm²/s

Acid value

  EN 14104

0.0

mg(KOH)/g

Residue after evaporation

  NF T 30-084

0

%

Vapour pressure at 20°C

  NF EN 13016-1

0.79

hPa

Distillation range at atmospheric pressure

ISO 3405.2019

182 – 190

°C

PERFORMANCE CHARACTERISTICS

PROPERTIES

  STANDARDS

VALUES

UNITS

KB index

  ASTM D 1133

not applicable

-

Evaporation rate at 20°C, zero air flow

-

2:15

h.mn

Surface tension at 20°C

  ISO 6295

26.1

Dynes/cm

Copper blade corrosion 100h at 40°C

  ISO 2160

1a

Rating

FIRE SAFETY PROPERTIES

PROPERTIES

  STANDARDS

VALUES

UNITS

Flash point (vacuum)

  ISO 2719

 66

°C

Self-ignition point

  ASTM E 659

207

°C

Lower explosive limit

  NF EN 1839

 0.7

% (by volume)

Upper explosive limit

  NF EN 1839

23.6

% (by volume)

ENVIRONMENTAL PROPERTIES

PROPERTIES

  STANDARDS

VALUES

UNITS

Sulphur content

  GC-MS

0

%

Benzene content

  ASTM D6229

0

%

Total halogen content

  GC-MS

0

%

Aromatic solvent content

  -

0

%

Environmentally hazardous substances content

  CLP Regulation

0

%

Content of compounds with a GWP

  -

0

%

Content of compounds with an ODP

  -

0

%



USES



solvents fountains

rotary or linear movement of basket machines



solvant de nettoyage de securite, SANS PICTOGRAMME DE DANGER special encres, resines, vernis, peintures. Sans odeur. Solvant pour serigraphie, tampographie. Utilisable sur fontaines de nettoyage. Solvant degraissant, Solvant de sécurité, Solvant biodegradable, Solvant sans pictogramme, Solvant non etiquete, Degraisssant de securité, Solvant pour encres, Solvant resines, Solvant colles, Solvant degraissant industriel, Fabricant solvants industriels, Solvant nettoyant, Solvant de nettoyage, Solvant pour fontaines de nettoyage, Produit fontaine de nettoyage, Solvant peinture pour fontaines, Solvant nettoyant encre, Solvant nettoyant peinture . fabricants solvants de nettoyage. Fournisseurs solvants de nettoyage. Solvants. Solvant de securite. Solvant sans pictogramme de danger. Solvant de nettoyage sans odeur. Solvant pour serigraphie. Solvant pour tampographie. Solvant traces adhesifs. Solvant machine de lavage. Solvant pour bacs ultra sons. Nouveaux solvants. Nouveau solvant. Substitut dichloromethane. Substitut chlorure de methylene. Substitut ch2 cl2. Substituts CMR. Substitut acetone. Substitut acetone. Substitut NMP. Solvant pour polyurethanes. Solvants pour epoxy. Solvant polyester. Solvant colles. Solvant peintures. Solvant resines. Solvants vernis. Solvants elastomeres



tanks for cold or hot immersion

ultrasonic tanks





spray washing machines

A3 machines
